Friday 31 October 2014

Portable Power Sprayer: YC26K

click on the photo to close this window

Pump                         : Horizontal Gear Driving Type
Plunger                      : 1 pc (two-way operation)
Cylinder                     : 2 pcs
Dia. of plunger           : 16mm
Stroke                        : 9mm
Spraying vol.              : 7.2liter/min
Pressure                    : 30 ~ 35kg/cm^2
Engine                       : Zenoah G26LS (made in Japan)
Horepower                 : 1.4HP
Air consumption         : 25.6cc
Max. ratio of fuel        : 25:1
Dimension                  : 42 x 34 x 32 cm
Weight                        : 9kg
Origin                          : Taiwan

Monday 13 October 2014

Sonnenflex: Cutting Wheel/ Cutting dics


Silverstar cutting wheels are in general suitable for craftsman and the stone and metal working industry with outstanding price-performance ratio.


Application: Stone and steel

Usage: For general use on building materials including structural metalwork and reinforcement.


Pros: Hard, long lifetime.


Origin: Made in Germany (High quality control)


Model:


CW-12-20 : 300x3.5x20mm
CW-12-22 : 300x3.5x22mm
CW-14-20 : 355x4.0x20mm
CW-14-22 : 355x3.0x22mm

Tuesday 7 October 2014

Zenoah: 2 in 1 Chain saw + Auger


The Atom converts a Chainsaw into a Power Drill. Compared with the cost of hand methods the Atom can pay for itself in just a few days. Ideal for drilling strainers posts for farm gates and fence posts for wire and many other uses.




Thursday 25 September 2014

Rover: Lawn Mowers Alloy 18"

Regal Mulch n Catch




The Rover Lawn Mower has an 45cm (18") alloy deck and a Rover OHV 800 engine. It features 4 swing back blades for superior cutting and protects the engine if a solid object is hit. It is ideal for those with medium to large blocks.




EngineRover OHV 800 Engine, 159cc fixed throttle with primer
Deck45cm (18") high arch reinforced alloy for strength and flexibility that cuts or mulches to the edge both sides
Engine BrakeStandard - stops the engine upon release of the handle and complies with Australian Standards (AS2657)
Cutting OptionsMulch N Catch - rear discharge catcher or mulch
Blades4 swing back blades for superior cutting and protects the engine if a solid object is hit


You any y question? Contact us  via email: yiehongm@yahoo.com or call us @ +603-7785 5369.



Welcome to visit our website: http://www.yiehongsb.com

Wednesday 10 September 2014

Pole saws: PSJ2310 (Made in Japan)

Zenoah pole saws allow you to prune the branches of tall trees easily and speedily.





Displacement: 22.5cm^3

Power: 0.7kW (0.9Hp)

Dry weight: 5.9kg (10")

Bar: Oregon 90Micro-lite 10"

Chain: 25AP-J58E (10")

Handle: Loop

Carburetor: Diaphragm

Ignition system: CDI

Fuel tank: 0.60lit.

Overall: 286cm


Website: http://www.yiehongsb.com



Friday 29 August 2014

Lightweight Japan blower for home use. HB2302


Zenoah lightweight blowers with 2-cycle engine make cleaning up your property easy.

It do not only remove leaves but also litter quickly and easily and therefore can be used throughout the year.






ONLY 3.7KG!


Model                                      HB2302
Displacement                           22.5 cm^3
Power                                      0.9 kW/ 1.2 Hp
Air volume                               10.0 m^3/min
Max air velocity                        67.0 m/sec
Fuel tank                                  0.75 lit


** Made in Japan.






Sunday 24 August 2014

Wuli High Pressure Accessories

High Pressure Hose



(a) Max. 2,500 p.s.i


  • 5/16 * 1 W
  • Model: M-H1-5
  • Only RM13.00/meter

(b) Max. 4,250 p.s.i

  • 5/15 *2 W
  • Model: M-H2-5
  • Only RM17.00/ meter

** Including PT1/4 Male Adapter at both side.


Wednesday 9 July 2014

New Promotional Video: ZENOAH - Made in Japan & Japan Quality


We are pleased to inform you that new Zenoah promotion video was completed at last.

Feel free to take a few second to ENJOY the video!!








YIE HONG SDN BHD

11, JALAN 2/152,
TAMAN PERINDUSTRIAN O.U.G,
BATU 6, JALAN PUCHONG,
58200 KUALA LUMPUR.
TEL: +603-778-55369




Wednesday 14 May 2014

User comment: Chain Saw GZ4000


With its power-to-weight ratio and performance, the Zenoah chainsaw is the commercial user's best friend. The GZ4000 is an excellent all-around saw, ideal for cross cutting, as well as limbing and light duty work. The 40.1 cc Strato-Charge engine (http://yiehong.blogspot.com/2014/05/strato-charged-engine.html) produces ultra-low emissions without compromising power. Easy access air filter reduces down-time in the field. Additional features include inertia-activated chain brake, chain catcher, throttle interlock, right hand guard and easily accessible stop switch.





source: http://www.redmax.com/products/chain-saws/gz4000/

Buying Guide: Chain Saw

When you decide to buy a chainsaw you should naturally consider your own needs first. What do you want it for? How often will you use it? Do you work in the forest every day or do you just need it to cut firewood?

Things to keep in mind when buying a chainsaw:

• Safety is important. Make sure the saw has essential safety features such as kickback protection, chain brake, right hand guard and catcher stud.

• Are both handles adequately protected from vibration? Vibration will quickly cause fatigue.

• Choose a powerful enough saw right from the start. Many people buy an underpowered saw the first time.

• Is the air filter system designed to avoid clogging with sawdust?

• Is the saw easy to maintain? Is there a good user manual?

• Will the saw run on unleaded petrol? Can you use vegetable-based chain oil?

• Can the dealer service your saw? Do they have spare parts and accessories?

• Can the dealer demonstrate the saw? Do they offer useful operating instructions on video and in brochures?

• Can the dealer supply you with the necessary protective equipment?

• Do you want to work indoors and outdoors? If so, buy a good electric saw that is built by professionals.

Buying Guide: Blower

There are various types of blowers, including our handheld and backpack types. With a blower you can do much more than just move leaves: you can also clean up debris, grass clippings, hedge clippings etc.

Things to keep in mind when buying a blower:

• The machine should have an efficient vibration-dampening system to minimise vibrations from those parts of the machine that the user comes in contact with.

• The engine should be powerful and easy to start.

• Pay attention to air speed and air flow.

• If you choose a backpack blower, it should have a comfortable and load-reducing harness with hip belt and wide shoulder straps.

Thursday 8 May 2014

Zenoah Japan Strato-Charged Engine


The Strato-Charged engine passed the world's first California Air Resources Board (CARB) the secondary emission control without a catalyst.


Introduced in 1998, our state-of-the-art Strato-Charged® engines are designed with advanced technology that reduces impact on the environment through efficient engine design, increased fuel economy and reduced emissions.

For ten years, this proven technology has delivered maximum performance in a light, rugged design with outstanding features that set it apart from the competition. The Strato-Charged® 2-stroke engine:

Achieves up to 20% more fuel efficiency than standard 2-stroke engines

• Produces low emissions that meet regulations without the need for a heated, heavy catalytic converter

• Requires no valve adjustments, oil changes or daily oil reservoir level checks

• Generates 15 to 20% more horsepower than a typical 4-stroke or 4-stroke hybrid engine of the same engine displacement size



Strato-Charged® 2-stroke engines operate at maximum efficiency with just three moving parts. By comparison, 4-stroke or 4-stroke hybrid engines contain as many as 30 moving parts. Strato-Charged® 2-stroke engines are 20 to 25% lighter per same engine size as compared to 4-strokes or 4-stroke hybrids, resulting in much less operator fatigue. Engines with a high power to weight ratio and a high-power output per engine cc size are classified as high-performance engines, and these are the only type of engines made by ZENOAH.





Reciprocator - Very durable and Heavy duty.

Highly regarded among landscaping professionals, the commercial-grade reciprocator by ZENOAH can handle the most difficult trimming, edging or pruning tasks. Designed for tough everyday use, the reciprocating blades work back and forth in a scissor-like motion without high-speed spinning. This allows users to trim and edge safely without throwing objects or dangerous debris. The superior performance of this outstanding product even withstands concrete edges, water, gravel and sand.

Top performance, combined with improved safety and simple maintenance make the ZENOAH reciprocator a preferred choice among landscaping, garden and park maintenance professionals everywhere. The reciprocator unit operates without kickback, which normally occurs when high-speed spinning blades strike a fixed object.

The reciprocator includes many additional design features, including our patented Strato-Charged engine technology. The reciprocator stands up to the competition in quality, durability and ease of use.

The Reciprocator is 4 Units in 1: Trimmer, Edger, Hedge Clipper and Pruner. The exclusive ZENOAH reciprocator can trim under fences, water, mulch and gravel, cut and shape sod, and shape sand traps. It can also edge along flower beds and vines, and around head stones and monuments without damage. The reciprocator can edge sidewalks, driveways and paths, planting beds and trees without harming bark. The ZENOAH reciprocator is the single best tool you can own.
ZENOAH reciprocator has a good feedback from few Kuala Lumpur and Selangor GOLF CLUB.



Feedback from a US user:

Monday 28 April 2014

Which mist nozzle is correct?

Difference nozzle, difference output.

           Choose the output that you required and choose the correct nozzle.

Misting Pump


  • Forged Manifold: Anti-rust, non-leaking design extends the life of the pump.

  • Rinse Cooling Design: Internal rinse design channels water to packing to reduce heat stress and increase the life of the packing.

  • Dual Bearing Design: Lowers the heat and noise by reducing friction and wear.

  • Automatic Pressure Valve: Controls the consistency of the pressure, regardless of the number of nozzles used and nozzles becoming clogged.

  • Circuit Breaker: Stops the motor if the voltage is outside of the safety parameters.

Thursday 24 April 2014

ZENOAH Warrior

" Challenges to the future "


Nature Protection Robot
Zenoah Warrior

As a reliable warrior with the spirit of "Japan Quality", Zenoah will continue to support agriculture, forestry and landscape professionals with the leading-edge technology as typified by Strato-Charged engine to protect the green environment for the future.

Mist cooling system installation

Installation

Misting fan:

The cooling, misting or humidification effects depend on the sizes of misting fans, nozzle sizes, spacing between nozzles and the relative humidity.

Spacing:

Standard spacing between nozzles ranges from 0.5 to 1.5 meter. Standard spacing between pipelines is determined by nozzle output and the desired humidity to be created.

Pumps and Nozzles

The choices of pumps and nozzles are determined by the size of the installation size, the requirements of cooling, misting, and humidification effects and the humidity in the air.

Pump:

The pump is determined by the number and size of nozzles used. For example, if the flow of a nozzle is 46cc/min and there are three hundred nozzles used, then the total volume of water required per minute is 13,800cc (46 x 300). Please use a pump with a minimum output volume of 13.8liters per minute. Generally, a pump with pressure more than 70kgf/cm^2 will achieve the best results.

Nozzles:

For best fogging effects, choose nozzles with small orifice sizes to reinforce cooling effects and to avoid dripping. This also helps to increase the negative ions in the air.

Maintenance

Nozzle:

Put nozzle in a container with 70c water and use mineral deposit dissolver to soak the nozzles for 4 hours; then, use an ultrasonic cleaner to clean the nozzle.


  • On-site installation
  • Adjustable nozzle angle
  • Easy maintenance
  • Durable design, resists chemicals and UV rays

Why do we need mist cooling system? 为何需要微雾降温系统?

(a) Suppress Dust 防尘



(b) Add Humidity 加湿



(c) Lower Temperatures 降温





(d) Neutralize Odor 除臭





Taiwan Power sprayer, Suction vol.: 146l/min




Kerja anda perlu guna air yang banyak untuk mencuci atau membasuh?

Kerja anda perlu guna beberapa batang "spray gun"?

Kerja anda perlu guna air yang banyak untuk menghantar ke atas bukit?

Kerja anda perlu menguji tekanan dengan cepat?


WULI Power Sprayer boleh membantu anda!!



Wednesday 23 April 2014

Model berlainan, Fungsi berbeza 各有千秋 (1)

Persekitaran berbeza - Permintaan berlainan

Model berlainan - Fungsi berbeza

" Ringan  。 轻  。Light "

Model                                      HB2302
Displacement                           22.5 cm^3
Power                                      0.9 kW/ 1.2 Hp
Air volume                               10.0 m^3/min
Max air velocity                        67.0 m/sec
Dry weight                                3.7 kg
Fuel tank                                  0.75 lit
Air filter                                     Dry polyurethane foam


" Senyap  。静  。 Quiet "

Model                                       EBZ5100
Displacement                           50.2 cm^3
Power                                      1.6 kW/ 2.2 Hp
Air volume                               13.8 m^3/min
Max air velocity                        76.3 m/sec
Dry weight                                9.4 kg
Fuel tank                                  2.1 lit
Air filter                                     Half-wet single stage filter
Strato-charged engine              YES




Call us at +603-7785-5369 or email us at yiehongm@yahoo.com

Model berlainan, Fungsi berbeza 各有千秋 (2)

Persekitaran berbeza - Permintaan berlainan

Model berlainan - Fungsi berbeza

" Kuat 。强 。Strong "


Model                                       EB6200
Displacement                           62.0 cm^3
Power                                      2.9 kW/ 3.9 Hp
Air volume                               15.0 m^3/min
Max air velocity                        83.0 m/sec
Dry weight                                8.6 kg
Fuel tank                                  2.0 lit
Air filter                                     Half-wet polyurethane foam


" Kencang  。 猛  。Fierce "



Model                                       EBZ8500
Displacement                           75.6 cm^3
Power                                       3.3 kW/ 4.4 Hp
Air volume                                25.7 m^3/min
Max air velocity                        92.2 m/sec
Dry weight                               11.1 kg
Fuel tank                                  2.3 lit
Air filter                                     2-stage freshflow filter system


Interested?
Please contact us at +03-7785-5369 or yiehongm@yahoo.com

Who is YIE HONG?

Who is YIE HONG?

YIE HONG incorporated in 1992 and has been leading by Mr Nai Tong Hup and Mr Chua Thong Hiang. Both of them have more than 40 years' market experience in this industry.  Our sincerity and hard work has helped us earned trustworthy reputation and built good relationship with our business partners as well as our principals.

YIE HONG bring in two well-know brand, WULI from Taiwan and ZENOAH from Japan.

WULI and Zenoah are not only sell by us. Our products are now well distributed in over Malaysia. We have more than 100 dealers in Malaysia.


Office address:
No.11, Jln. 2/152,
Taman Perindustrian OUG,
Batu 6, Jalan Puchong,
58200 K.L

Tel: 603-7785-5369
Fax: 603-7785-2212

Sales Manager: Ms Lily

Tuesday 22 April 2014

When do we need high pressure cleaner?



Applications:

  • Cleaning: Ideal for use with cars, buses, trains, aircraft, ships, buildings and construction sites.
  • Pressure testing: Testing couplings, hardware, hoses or pipes.
  • Misting system: Flash evaporation mist cooling for applications of all sizes.
  • Neutralize odor: Spray disinfectant or fragrances to improves air quality.
  • Add humidity: Fine droplet misting for mushroom farms, textile mills and other factories.
  • Carwash system: High-volume pumps are suitable for a wide range of carwash tunnels and multi-bay establishments.
  • Food industry: Pumps with stainless steel manifold resist corrosion and contamination.




Model available in Malaysia:



** Our pump are available in 3 types:
  1. Pump only
  2. Pump with motor
  3. Pump with engine
Interested? Contact us at ...

YIE HONG SDN. BHD.
NO.11, JALAN 2/152
TAMAN PERINDUSTRIAN OUG
BATU 6, JALAN PUCHONG,
58200 KUALA LUMPUR

TEL: +603-778-55-369
EMAIL: yiehongm@yahoo.com

Monday 21 April 2014

Everything cool under the sun



  • Adjustable high up to 190cm

  • 3 speed, variable pitch oscillating fan

  • hose connector inlet with float valve shutoff

  • 38 litter tank for 2 hours of continuous misting

  • High pressure mist pump  (W.P 70bar)

  • Wheel lock for greater safety and stability

  • Motor circuit breaker for electrical safety

  • Fan can be separated from the main unit for easy handling

  • Two 10" rear wheels and one heavy duty caster for easy mobility

  • Pretty outlook



YIE HONG SDN BHD

11, JALAN 2/152,
TAMAN PERINDUSTRIAN O.U.G,
BATU 6, JALAN PUCHONG,
58200 KUALA LUMPUR.
TEL: +603-778-55369


User comment: Blower EBZ8500





User comment on EBZ8500



Source: http://www.redmax.com/products/blowers/ebz8500/

Sunday 20 April 2014

Tiupkan daun basah! 吹起湿叶!

Selepas hujan, susah sapu daun basah?

                    Zenoah Blower boleh bantu awak!!





Jimat Masa, Kerja Senang

We have blower range from 50.2cc to 75.6cc. See www.yiehongsb.com for details or contact us at +603-7785-5369 or email us at yiehongm@yahoo.com. We are ready to serve U!!



Friday 18 April 2014

Duster / Misters - MD6210M

" Specially designed water-spraying mister"



Semburan cecair 12L/min

每分钟排水量 12公升


Model                                      MD6210M-18
Displacement (cm^3)              62.0
Power (kW/ Hp)                      2.8 / 3.8
Dry weight (kg)                       11.7
Caburetor                               Diaphgram
Fuel tank (lit)                          1.8
Tank capacity (lit)                   18
